60048 single point Loadcell
11, 22.5, 45, 90 Kg | Dynamic Weighing | IP68
₹5000.00
60048 single point Loadcell is designed for dynamic weighing applications that need precise single-point measurement and stable industrial performance. It offers accurate output, high durability, and easy system integration for Ahmedabad, Gandhinagar, and nearby industrial markets.
Parameter | Value |
|---|---|
Product Name | 60048 single point Loadcell |
Model Name/Number | 60048 single point Loadcell |
Brand | KP Control and Automation |
Capacity | 11,22.5,45,90 (KG) |
Material | Alloy Steel |
Ingress Protection | IP68 |
Application | Dynamic Weighing |
Original Mentioned Model | KP-60048 |
Features | High Accuracy & Precision |
Output Sensitivity(FS) | 2.0 +/- 0.002 mV/V |
Zero balance | +/- 1% FS |
Maximum Safe Overload | 150% FS |
Ultimate Safe Overload | 180% FS |
Recommended Excitation Voltage | 5 to 12V DC |
Insulation resistance at 50V DC | >= 5000 M Ohm |
Compensated Temperature Range | -20 to +70 Deg C |
Operating Temperatue Range | -10 to +40 Deg C |
Cable Length | 5 mtr |
Parameter | Value |
|---|---|
Suitable For | Dynamic Weighing |
Capacity Range Mentioned | 5 kg to 5 ton |
Performance | High precision, stable output, reliable performance |
Installation | Easy installation and system integration |
