Brand
|
Thames
|
|
Model
|
T20
|
|
Material
|
Stainless Steel
|
|
Ingress Protection
|
IP68
|
|
Application
|
Tank, Silo & Vessel Weighing
|
|
Capacity
|
2.5 Ton- 30 Ton
|
|
Features
|
Hermetically Sealed, High Accuracy & Precision
|
|
Load Cell Certifications
|
OIML, ATEX
|
|
Output Sensitivity(FS)
|
2.0 +/- 0.1 mV/V
|
|
Combined Error
|
<= +/- 0.05
|
|
Creep Error (30 minutes)
|
<= +/- 0.05
|
|
Accuracy Class
|
OIML R60 C3
|
|
Temperature Effect on Zero
|
<= +/- 0.002
|
|
Temperature Effect on Output
|
<= +/- 0.0036
|
|
Zero balance
|
+/- 1% FS
|
|
Maximum Safe Overload
|
150% FS
|
|
Ultimate Safe Overload
|
200% FS
|
|
Recommended Excitation Voltage
|
10 to 12V DC
|
|
Maximum Excitation Voltage
|
15V DC
|
|
Input Resistance
|
800 +/- 30 Ohm
|
|
Output Resistance
|
700 +/- 5 Ohm
|
|
Insulation resistance at 50V DC
|
>= 5000 M Ohm
|
|
Compensated Temperature Range
|
-10 to +40 Deg C
|
|
Operating Temperatue Range
|
-30 to +70 Deg C
|
|
Load Cell Intervals (nLC)/Divisions
|
3000
|
|
Cable Length
|
10 Meter
|
